Application : only characteristics of excellent electricity mechanism, and heat stress but also has simple structure, light weight, no restriction on laying drop & high temperature
allowance for long term working.
Conductor : Conductors are made from Electrolytic Aluminium/Copper conforming to IS : 8130, and are compact circular or compact shaped. Stranding makes the cable exible
while shaping makes them compact.
Core colour : Red, Yellow, Blue & Black.
Insulation : Shaped conductors are insulated with XLPE compound which has high Insulation and volume resistivity, along with higher current carrying capacity than PVC.
Inner-Sheath : Laid up and twisted conductors are provided with best in class extruded PVC which acts as a bedding for G.I. wire/strip armouring.
Armouring : Best in class hot dipped GI wire/strip are used for armouring the cable.
Outer-Sheath : Specially formulated ST-2 compound is used for outer sheathing of XLPE cables.
Marking : Sequential meter marking with generic marking “Bintex” at one meter interval.
Packing : Drum packing 500 mtr and above available on request.
