Application : Specifically designed for machine welding and hand welding to work in damp, dry, indoor and outdoor locations.
Types of welding cables :
- NBR single insulated
- NBR insulated + NBR sheathed
- HOFR insulated + NBR sheathed
- HOFR single Insulated
Construction :
Conductor : Ultra flexible class 6 bare annealed electrolytic copper
Seperator : BOPP polyster tape
Insulation : 1st covering of HOFR (Heat, oil and Flame retardant), 2nd Sheathing layer made of TPR compound
.webp)
OUTSTANDING ELECTRICAL AND MECHANICAL STRENGTH
HEAT AND OIL RESISTANT (HOFR)
EXCEPTIONALLY HIGH RESISTANT TO CUTS AND ABRASION
EXCELLENT FLEXIBILITY FOR LONG LASTING LIFE
| CROSS SECTIONAL AREA | NO. OF STRANDS/DIA. OF COPPER NOMINAL THICKNESS |
NOMINAL THICKNESS. |
OUTER DIA APPROX. |
MAX. CONDUCTOR RESISTANCE AT 20°C |
CURRENT RATING |
|||||
|---|---|---|---|---|---|---|---|---|---|---|
| WELDING APPLICATIONS |
||||||||||
| DUTY CYCLE |
||||||||||
| Sq. mm | Nos. / mm | mm | mm | ohm / km | 100% | 85% | 80% | 60% | 35% | 20% |
| 10 | 320 / 0.200 | 2 | 10.04 | 1.91 | 100 | 100 | 100 | 101 | 106 | 116 |
| 16 | 513 / 0.200 | 2 | 11.25 | 1.21 | 135 | 136 | 136 | 139 | 150 | 174 |
| 25 | 783 / 0.200 | 2 | 12.96 | 0.78 | 180 | 182 | 183 | 190 | 213 | 254 |
| 35 | 1121 / 0.200 | 2 | 14.82 | 0.554 | 225 | 229 | 231 | 243 | 279 | 338 |
| 50 | 702 / 0.300 | 2.2 | 16.78 | 0.386 | 285 | 293 | 296 | 316 | 371 | 457 |
| 70 | 999 / 0.300 | 2.4 | 19.17 | 0.272 | 355 | 367 | 373 | 403 | 482 | 602 |
| 95 | 1332 / 0.300 | 2.6 | 21.88 | 0.206 | 430 | 448 | 456 | 498 | 606 | 765 |
| 120 | 1702 / 0.300 | 2.8 | 24.03 | 0.161 | 500 | 524 | 534 | 587 | 721 | 917 |
